Smart Control Panel 7Pro+
$206.06 $206.06
Shipping calculated at checkout.
In stock
Description
  • Smart Control Panel 7Pro+ is a multi‑functional interactive device that combines touch control, voice control, a multi‑mode gateway, a dual‑channel relay, and infrared remote control.
  • Through touch and voice interaction, you can control various Powered by Tuya devices and scenes in your home. The multi‑mode gateway supports connecting Zigbee and Bluetooth Sigmesh sub‑devices. The dual‑channel relay can replace traditional switches to control two lighting circuits. The built‑in infrared remote control can directly control infrared devices such as TVs and air conditioners.
  • In addition to controlling devices and scenes, the Smart Control Panel 7Pro+ also supports smart cameras, video doorbells, and video door locks. You can view the camera’s audio/video stream directly on the screen, and when paired with a video door lock, you can unlock the door right from the screen.
Smart Control Panel 7Pro+
Scroll to section
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
iF Design Award 2025 Winner
One Screen. Total Control
Seamless Integration. Endless Possibilities
  • Ultra-Thin 8.2mm Profile: Designed with an industry-leading 8.2mm ultra-slim bezel—30% thinner than conventional control panels—fitting seamlessly into standard double 86 wall boxes and luxury interiors.
  • Patented Universal Rotation System: Supports flexible installation options including landscape, portrait, tandem wall mounts, or an optional desktop dock.
  • Self-Developed AliveOS with Bento UI: Modular card-based interaction allows users to access high-frequency scenes, lighting, HVAC, and real-time security camera feeds without navigating complex menus.
  • AI Voice Intelligence & Alexa Integration: Powered by an advanced AI Large Language Model (LLM) voice assistant alongside native Alexa Voice Service integration.
  • All-in-One Multi-Protocol Gateway: Fully integrates Zigbee 3.0, Bluetooth Sigmesh, Triple IR remote control, dual-band Wi-Fi, and an RJ45 Ethernet port. Fully compatible with Powered by Tuya ecosystems.
  • Built-in Dual-Channel Relays: Features built-in 2-way 200W relays, allowing direct replacement of physical light switches.

  • Screen Size: 6.9 inches
  • Screen Resolution: 1440*720Input: 100-240V~; 50/60Hz; 5A
  • Wireless Protocols: Wi‑Fi (2.4GHz/5GHz) , Zigbee 3.0 , Bluetooth 5.2/Bluetooth Mesh
  • Max Load: Total Max 400W , Single Channel max 200W
  • Operating Humidity: 5% ~ 90% RH (non‑condensing)

Product comparison

Smart Control Panel 7Pro+
Smart Control Panel 7Pro+
Smart Control Panel 7Pro+
Smart Control Panel 7Pro+
Current product Current
Xcessmart

Smart Control Panel 7Pro+

$206.06 $206.06
Options
In stock
Descriptions
  • Smart Control Panel 7Pro+ is a multi‑functional interactive device that combines touch control, voice control, a multi‑mode gateway, a dual‑channel relay, and infrared remote control.
  • Through touch and voice interaction, you can control various Powered by Tuya devices and scenes in your home. The multi‑mode gateway supports connecting Zigbee and Bluetooth Sigmesh sub‑devices. The dual‑channel relay can replace traditional switches to control two lighting circuits. The built‑in infrared remote control can directly control infrared devices such as TVs and air conditioners.
  • In addition to controlling devices and scenes, the Smart Control Panel 7Pro+ also supports smart cameras, video doorbells, and video door locks. You can view the camera’s audio/video stream directly on the screen, and when paired with a video door lock, you can unlock the door right from the screen.

FAQs

  • Ecosystem: It is natively built on the Tuya ecosystem (Powered by Tuya), enabling seamless interaction with a wide range of Tuya-enabled smart devices, lighting, and scenes. The panel runs on the all-new in-house developed AliveOS, offering a simplified, fast-responsive UI.
  • Voice & Control: It built-in Alexa Voice Service and features integrated 360° triple IR transmitters to directly control traditional infrared appliances like ACs and TVs.
  • Customization: We support UI customization, brand logo branding, and scene pre-configuration. If API/SDK integration or private cloud deployment is required, our engineering team can evaluate technical feasibility.

  • Integrated Gateway: The panel features a built-in multi-mode gateway supporting Wi-Fi (2.4GHz/5GHz dual-band), Zigbee 3.0, and Bluetooth 5.2 / Bluetooth Mesh.
  • Hardwired Reliability: In addition to dual-band Wi-Fi, the back module includes an RJ45 Ethernet port. This hardwired connection ensures ultra-low latency and maximum network stability when managing dense sub-device topologies.
  • Capacity: It can manage up to dozens/hundreds of Zigbee and Bluetooth Mesh sub-devices simultaneously, making it ideal for whole-home automation.
  • Junction Box Compatibility: The mounting base is universally designed for standard EU/UK 86-type boxes (60mm hole pitch), US-standard boxes (83.5mm pitch), and double 86-type tandem boxes (146mm pitch).
  • Wiring & Load: It requires a Neutral + Live wire power supply (100–240V~). It includes a built-in 2-way relay switch to directly control two lighting circuits (max 200W per channel, 400W total load).
  • Desktop Option: Beside wall-mounting, an optional magnetic desktop base is available, ideal for office desks, hotel reception areas, or retrofitting without wall modification.
  • Display & Design: Features a 6.9/7-inch HD display ($1440\times720$ resolution) with an ultra-slim, bezel-less design ("Thin as a Letter"). It has won the prestigious iF Design Award 2025, adding significant sales appeal to high-end residential and hospitality projects.
  • Certifications: Fully compliant with FCC Part 15 regulations and RoHS environmental standards, ensuring smooth customs clearance and compliance for global market distribution.
  • Intercom & Calling: Features Home Calling and two-way audio intercom capabilities, powered by dual-microphone arrays (with physical mute button/indicator) and built-in speakers.
  • Security Integration: Real-time video/audio streams from Tuya-compatible smart cameras, video doorbells, and video door locks can be viewed directly on the 7-inch display.
  • One-Touch Unlock: When a visitor rings a video doorbell or lock, the panel automatically triggers a live video pop-up with a one-touch remote unlock button right on the screen.
