Smart Dual Band Multimode Gateway
$17.42 $17.42
Shipping calculated at checkout.
In stock
Description

Dual Band Wireless Multi-mode Gateway XS-THP01-ZB-V5 is a ultra low cost multi-protocol gateway that supports 2.4GHz Wi-Fi, 5GHz Wi-Fi, Zigbee, SigMesh, single-point, Beacon Mesh and BLE Long Range devices communication.By connecting to the gateway you enable communication with the cloud and the app, allowing users to easily view and control up to 128 smart devices for each gateway that use the Zigbee/Bluetooth protocol.
Smart Dual Band Multimode Gateway
Scroll to section

See how this smart gateway works

Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
Seamless Whole-Home Control | 2.4GHz + 5GHz Dual-Band Gateway
Connect Hundreds of Smart Devices in One Reliable Network
Signal Strength Detection & Remote OTA Updates Built-in
  • Max Connectivity: Support Max 128 Zigbee devices, or 32 lowpower Zigbee devices, or 128 SigMesh devices, or 64 Beacon Mesh devices, orreal-time control of 4 single point/BLE Long Range devices, the max connectivity enriches smart home application scenarios.
  • Automatic Association: When you add new SigMesh/BeaconMesh devices through cellphone Bluetooth, they will be automatic association with gateway and realize remote control function.
  • One-Key Pairing: Short press the button on the gateway to enter thelong-term pairing mode (the indicator light will flash), and last for 1 hour. At this point, if the sub-devices are in pairing mode, the sub-deviceswill
    be added automatically. It supports multiple devices to be addedat the same time. You can press the button once again to turn off the one-keypairing mode.
  • Remote Control: Users can use APP/Voice （Alexa, Google Home... ）control devices through the gateway.
  • Cloud scene/automation: Through the scene and automation settingsinthe APP, the sub-device under the gateway can link with other smart devices(such as Wi-Fi plug).
  • Local scene/automation: The gateway prioritizes local scene/automation instead of Cloud scene/automation, which reduces the cloud delay. The local scene/automation responses quickly even when the external networkis disconnected.
  • Long/Short Connections: The gateway supports single point devices long connections and on-demand connections to sub-devices to meet thepower consumption requirements of different application scenarios.
  • OTA: Not only support gateway firmware OTA, but also support Zigbee, SigMesh, single point/BLE Long Range and Beacon Mesh sub-device firmware OTA through the gateway.
  • Signal Strength Detection: The gateway can detect the Wi-Fi signal strength between router & gateway and Zigbee/Bluetooth signal strength between sub-devices & gateway as well. It helps end user diagnose the connectivity issue quickly.
  • BLE Long Range：enabled by the Coded PHY mode in the Bluetooth5.0 protocol, provides a transmission range of over 300 meters, makingit suitable for low-power, long-range communication applications.
  • WirelessDual Band Zigbee+BluetoothMultimode Hub（With USB Cable）
  • Max Connect With 128 Devices
  • Power Input: 1A 5V
  • Battery Speciations: Micro USB DC5V
  • Opearting Temperature: -10℃-55℃
  • Operating Humidity: 10%-90% RH (No Condensation)
  • Wireless Technology: WiFi 802.11b/g/n, ZigBee 802.15.4

Product comparison

Smart Dual Band Multimode Gateway
Smart Dual Band Multimode Gateway
Smart Dual Band Multimode Gateway
Smart Dual Band Multimode Gateway
Current product Current
Xcessmart

Smart Dual Band Multimode Gateway

$17.42 $17.42
Options
In stock
Descriptions

Dual Band Wireless Multi-mode Gateway XS-THP01-ZB-V5 is a ultra low cost multi-protocol gateway that supports 2.4GHz Wi-Fi, 5GHz Wi-Fi, Zigbee, SigMesh, single-point, Beacon Mesh and BLE Long Range devices communication.By connecting to the gateway you enable communication with the cloud and the app, allowing users to easily view and control up to 128 smart devices for each gateway that use the Zigbee/Bluetooth protocol.

FAQs

The 2.4GHz band is often congested in apartments or offices, leading to frequent disconnections. Our dual-band (2.4GHz/5GHz) gateway utilizes the 5GHz frequency to minimize interference, ensuring high system stability in complex network environments and significantly reducing after-sales maintenance costs.

Powered by the Zigbee 3.0 protocol, this gateway supports up to 128 sub-devices. For villas or mid-sized hotel rooms, a single hub can manage all lighting, curtains, and sensors, making it a highly cost-effective solution for engineering projects.

Yes. This gateway supports local scene linkage. As long as the gateway and sub-devices have power, pre-set automations (e.g., a motion sensor triggering lights) will execute locally without relying on the cloud server, ensuring system reliability.

Our gateway is fully compliant with the standard Zigbee 3.0 protocol, allowing it to connect with most Tuya-compatible third-party devices. It seamlessly integrates with the Tuya Smart and Smart Life apps and supports voice control via Alexa and Google Home, making it easy to integrate into existing smart systems.
